20w Portable Laser Marking Machine 0.01mm Working Accuracy For LED Lights

  • 20w Portable Laser Marking Machine 0.01mm Working Accuracy For LED Lights
  • 20w Portable Laser Marking Machine 0.01mm Working Accuracy For LED Lights
Place of Origin Shenzhen
Brand Name Riselaser
Certification ISO9001:2008 CE
Model Number RL-20P
Minimum Order Quantity 1
Price negotiation
Packaging Details Wooden Case
Delivery Time 5-9 working days
Payment Terms T/T, MoneyGram, Western Union
Supply Ability 2000 units/ month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Application Laser Marking Laser Type Fiber Laser
Certification CE After-sales Service Provided Engineers Available To Service Machinery Overseas
Product Name Fiber Laser Marking Machine Warranty Period 1 Years
Place Of Origin Shenzhen, China Power(W) 20W/30W/50W
Brand Name Riselaser Working Accuracy 0.01mm
Highlight

fiber laser etching machine

,

laser marking equipment
Leave a Message
Product Description



20W high quality hot sale portable fiber laser marking machine for LED lights



Products Description:



Fiber laser marking was specially developed for industrial marking. The robust design with maintenance-free laser source guarantees constantly precise marking on the workpiece. This kind od fiber laser marking machine due to its laser beam is thin, the processing material consumption is small, and the processing heat affected area is small, so its your best choice.



20w Portable Laser Marking Machine 0.01mm Working Accuracy For LED Lights 0T





Main features for this 20W high quality hot sale portable fiber laser marking machine



1. Optical Fiber Laser, environment friendly, easy maintenance.
2. The laser life can be up to 100000 hours.
3. Small volume and weight, less than 40KGS.
4. Runs without consumable spare parts, no need maintenance, great for continuous working.
5. User-friendly controller and software make operation easier.
6. Compact, lightweight, simple interface, flexible and adjustable processing direction.
7. The master switch, red light switch and galvanometer switch.

8. High-speed scanning galvanometer guarantee high marking speed and high precision.

9. High precision scale.



Technical Parameters:



Product Fiber Laser Marking Machine
Fiber Laser Brand Standard: MAX
Fiber Laser Lifetime 100,000 hours
Fiber Laser Power 20W, 30W, 50W
Beam Quality M2≤1.2
Max. Marking Speed 12000mm/s
Laser Wavelength 1064nm
Marking Area Standard: 110mm*110mm
Optional: 70mm*70mm, 150mm*150mm, 200mm*200mm, 300mm*300mm
High-speed Galvanometer Yes
Lens F-Theta Lens
Fiber Laser Repetition Frequency 20KHz-80KHz
Minimum Character 0.05mm
Marking Depth ≤5mm
Repeated Accuracy ±0.001mm
Minimum Linewidth 0.01mm

Positioning accuracy

 0.01mm

Repeatability

 0.01mm
Volt 110V, 220V, or according to your request
Cooling Mode Air Cooling
Graphic Format Supported PLT, DXF, DXP, AI, GIF, TGA, PNG, TIF, TIFF, DST, DWG, LAS, SDT,BMP,JPG,JPGE ,etc
Software Supported CORELDRAW, AUTOCAD, PHOTOSHOP, etc
System Supported Windows, MAC OS
Operating Ambient Temperature 5°C-45°C
Marterial Supported Metal and Some Non-metal
Marking Software EZCAD
Desktop Computer Yes
Training Videos, User Manua Yes
Warranty 2 years
Fiber Test Results Yes
Certificates FDA, CE, ISO,RoHS, EUT, FC,CCC,PSE,IC
USB 2.0 Compatible YES
Size (L*W*H) 720mm*210mm*510mm
Weight 40KG
Optional Laptop, Rotary Device
Packing Wooden case





Fiber Laser Marker Details:

20w Portable Laser Marking Machine 0.01mm Working Accuracy For LED Lights 1



Marking samples:



20w Portable Laser Marking Machine 0.01mm Working Accuracy For LED Lights 2
