Portable 20w Fiber Laser Marking Machine For Metal Stainless Steel Brass Aluminium
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Spot Size In Focus | 0.15mm | Marking Scope | 110x110~ 300x300 |
|---|---|---|---|
| Marker Speed | ≤15000mm/s | Min Line Width | 0.05mm |
| Min Character | 0.15 Mm | Repeat Precision | ±0.002mm |
| Highlight | portable 20w fiber laser marking machine,Fiber Laser Marking Machine 20 watt,20 watt fiber laser engraver |
||
Product Description
Handheld 20 Watt Fiber Laser Marking Machine For Metal Stainless Steel Brass Aluminium
Handheld Fiber Laser Marking Machine Features
1. The fiber laser generator is highly integrated, with superior laser beam and uniform power density. The output laser power is stable. This design greatly improves the anti-reflection ability of the machine through the optical isolator, and can mark most high-reflectivity materials (such as aluminum, copper, gold and silver) without shadows and virtual opening.
2. It adopts advanced digital high-speed scanning galvanometer, which has fast speed, no deviation, small size, good stability, and its performance has reached the international advanced level.
3. Modular design, separate laser generator and lifter, more flexible, can mark on larger area and complex surface. The interior is air-cooled, with a small footprint and easy installation.
4. Using embedded operating system, performance is ahead of domestic counterparts, good touch interface and powerful control system, can meet the needs of most industry application processes on the market.
Handheld Fiber Laser Marking Machine Application
It is very suitable for all metal materials, such as ordinary metals
(Iron, copper, etc.), rare metals (gold, silver, platinum, titanium, etc.), metal oxides
(Alumina, zirconia, etc.), special surface treatment (plating, etc.),
And also suitable for various non-metallic materials, such as ABS, ink, nylon,
PVC, epoxy resin, etc.
Handheld Fiber Laser Marking Machine teachnical data
| Laser Type | Fiber |
| Modol | RL-20PS |
| Certificatons | CE, ISO,OTHER |
| Power | 20W(30W,50W optional) |
| Brand | SUNDOR |
| Country of Origin | CHINA |
| Work Precision | ±0.01mm |
| Support Format | PLT, DST, AI, DXF, BMP, JPG, CAD,CDR, DWG,PCX |
| Software | EZCAD |
| Cooling Way | AIR COOLING |
| NC | YES |
| Condition | NEW |
| Work Area (mm) | 110x110/175x175(Customized) |
| Min Line Width | 0.017mm |
| Min Character | 0.15mmx0.15mm |
| Wavelength | 1064nm |
| After-Service | Engineers available to service machinery overseas |
| Laser Repetition Frequency: | 20KHz-80KHz(adjustable) |
| Power Demand | AC220V/50HZ/2A |
| Optimum Working Temperature | 10-35 °C |
| Marking Depth | 0.01-1.0mm(subjejct to material) |
Video
FAQ of Handheld Fiber Laser Marking Machine
1. How long does it take to learn how to use a laser marking machine?
We will use instructional videos for learning, and we can also help you learn laser online. It usually takes several hours to operate the laser, but understanding which speed and power settings to use for different materials will require trial and error. Therefore, we provide a comprehensive guide in your system, which suggests speed and power settings for the various materials you will be using.
2. Will the laser machine be safe during transportation?
(1) Inside: plastic stretch film and white foam.
(2) Medium: small pieces of wood and screws.
(3) Outside: standard export wooden box. Therefore, the laser machine will be sent to you safely. In case the machine is damaged, please contact us and we will replace it as soon as possible to ensure timely delivery.
3. What should I do if there is a problem with the laser?
We provide a two-year warranty. During the warranty period, we will provide damaged items free of charge. During the warranty period, we still provide maintenance services.
