GW CW Manual Laser Welding Machine Aluminum Laser Welding Machine
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Key Words | Handheld Welding Machine | Key Words 2 | Manual Laser Welding Machine |
|---|---|---|---|
| 3 In 1 Function | Welding, Cleaning And Cutting | Laser Type | GW CW Fiber Laser Or Raycus/ Max |
| Laser Power | 1500w | Machine Weight | 160KG |
| With | Auto Wire Feeding System | Packing Weight | 180KG |
| Cooling System | Built-in Water Chiller | Fiber Wire Length | 10M-15M |
| Machine Size | 745*516*710mm | Electrical Supply | 220±10% V AC, 50/60Hz |
| Highlight | GW CW manual laser welding machine,Raycus Max manual laser welding machine,1500w aluminum laser welding machine |
||
Product Description
1500w 2000w manual laser welding machine to do aluminum laser welding machine
Introduction
Riselaer Handheld Welding Machine RL-F series is an all-in-one hand-held fiber laser welding machine, including CW/pulse output mode. Suitable for welding stainless steel, iron, galvanized and aluminum. The features of weaving welding technology, adjustable focal length and the highest process consistency ensure the high-quality products of RL-F in the laser industry. Laser beam welding is a welding technique that joins metal pieces by using a laser. The beam provides a concentrated heat source for narrow, deep welds and high weld rates.
Specification
| Laser Beam | 1500watt GW Continuous Wave Fiber Laser,Emission Wavelength 1080±5nm |
| Cooling | Built-in Industrial Chiller(Purified water or distilled water) |
| Cable length | Fiber cable lenght 10m, Operable cable length 8m |
| Cleaning head | 0.75kg cleaning head |
| Wobble width | Adjustable 20-100mm |
| Protection Gas | compressed gas Pressure 5-10L/min |
| User Interface | For Laser Control:Power,Frequency, Frequency,Spot width |
| Language | Chinese-English |
| Safty | Class 4 laser equipment,Machine with CE,FDA certificate. |
| The machine comes with error alarm function,emergency stop,chiller alarm. | |
| Power Requirement | 220±10% V AC, 50/60Hz |
| Operating Ambient Temperature(℃) | 10~40℃ |
| Humidity (%) | 90 |
| Dimensions(W×H×D) | 745*516*710mm |
| Weight | 160kg |
Main components of this machine
Automatic wire feeder
Automatic wire feeder for seam welding less than 1.6mm
adjustable speed
Wire coil weight less than 15kg
Wire diameter 0.8, 1.0, 1.2, 1.6mm, aluminum 1.2mm
Support welding methods
Laser head
With 6 light spot modes (O, ●, 8, ◎, -, △)
The spot size can be adjusted from 0.2-5mm,
Simple operation, fingertip digital selection and adjustment
Can significantly improve welding efficiency.
Can be equipped with automatic wire feeding device
Water cooling device
Built-in industrial chiller, no external chiller required
Built-in water temperature alarm function, safe production
Dual temperature dual control
Machine features
Laser machining has proven to be a high-quality, cost-effective manufacturing process that requires minimal tooling. The reduction in tooling/fixtures makes laser machining ideal for prototyping. Compared to conventional TIG welders, the RL-F handheld laser welder is 4 times faster.
Safety design features maximize operator protection. Easier to handle and deliver consistent, high-quality results across a wide range of materials and thicknesses with minimal heat-affected zone to ensure aesthetics.
Low power consumption, low noise operation, no need for special temperature conditions, welding of dissimilar, high melting point metals are well-known advantages of laser welding machines. HW-A adopts integrated design, small size, suitable for various working environments.
The RL-F is the smallest and lightest water-cooled laser welding system in Riselaer's welding products. Less skilled operators can produce high-quality welds.
